Ghosts of Discovery Harbor: Digging for Data

Death by starvation, drowning, and execution was the fate of 19 members of the US Army’s Lady Franklin Bay Expedition that was charged in 1881 to explore the northern reaches of the American continent. Only six members returned alive, however, they carried papers of tidal observations that they had made at Discovery Harbor at almost 82 N latitude, less than 1000 miles from the North Pole. Air temperatures were a constant -40 (Fahrenheit or Celsius) in January and February. While I knew and wrote of this most deadly of all Arctic expeditions, only 2 days ago did I discover a brief 1887 report in Science that a year-long record of hourly tidal observations exist. How to find these long forgotten data?

My first step was to search for the author of the Science paper entitled “Tidal observations of the Greely Expedition.” Mr. Alex S. Christie was the Chief of the Tidal Division of the US Coast and Geodedic Survey. He received a copy of the data from Lt. Greely. His activity report dated June 30, 1887 confirms receipt and processing of the data, but he laments about “deficient computer power” and requests “two computers of standard ability preferable by young men of 16 to 20 years.” Times and language have changed: In 1887 a computers was a man hired to crunch numbers with pen and paper.

Data table of 15 days of hourly tidal sea level observations extracted from Greely (1888).

Data table of 15 days of hourly tidal sea level observations extracted from Greely (1888).

While somewhat interesting, I still had to find the real data shown above, but further google searches of the original data got me to the Explorer’s Club in New York City where in 2003 a professional archivist, Clare Flemming, arranged and described the “Collection of the Lady Franklin Bay Expedition 1881-1884.” This most instructive 46 page document lists the entire collection of materials including Series III “Official Research” that consists of 69 folders in 4 Boxes. Box-4 File-15 lists “Manuscript spreadsheet on Tides, paginated. Published in Greely (1888), 2:651-662” as well as 3 unpublished files on tides and tide gauges. With this reference, I did find the official 1888 “Report on the United States Expedition to Lady Franklin Bay” of the Government Printing Office as digitized from microfiche as

https://archive.org/details/cihm_29328

which on page 641 shows the above table. There are 19 more tables like it, but at the moment I have digitized only the first one. Unlike my colleagues at the US Coast and Geodedic Survey in 1887, I do have enough computer power to graph and process these 15 days of data in mere seconds, e.g.,

Hourly tidal observations at Discovery Harbor taken for 15 days by Greely in 1881 and Peary in 1909.

Hourly tidal observations at Discovery Harbor taken for 15 days by Greely in 1881 and Peary in 1909.

A more technical “harmonic” analyses reveals that Greely’s 1881 (or Peary’s 1909) measured tides at Discovery Harbor have amplitudes of about 0.52 m (0.59) for the dominant semi-diurnal and 0.07 m (0.12) for the dominant diurnal oscillation. My own estimates from a 9 year 2003 to 2012 record gives 0.59 and 0.07 m for semi-diurnal and diurnal components. This gives me confidence, that both the 1881 and 1909 data are good, just have a quick look at 1 of the 9 years of data I collected:

Tidal sea level data from a pressure sensor placed in Discovery Harbor in 2003. Each row is 2 month of data starting at the top (August 2003) and ending at the bottom (July 2004).

Tidal sea level data from a pressure sensor placed in Discovery Harbor in 2003. Each row is 2 month of data starting at the top (August 2003) and ending at the bottom (July 2004).

There is more to this story. For example, what happened to the complete and original data recordings? Recall that Greely left Discovery Harbor late in the fall of 1883 after supply ships failed to reach his northerly location two years in a row. This fateful southward retreat from a well supplied base at Fort Conger and Discovery Harbor killed 19 men. Unlike ghostly Cape Sabine where most of the men perished, Discovery Harbor had both local coal reserves and musk ox in the nearby hills that could have provided heat, energy, and food for many years.

It amazes me, that a 1-year copy of tidal data survived the death march of Greely’s party. It took another 18 years for the complete and original records to be recovered by Robert Peary who handed them to the Peary Arctic Club which in 1905 morphed into Explorer’s Club of New York City. I suspect (but do not know), that these archives contain another 2 years of data that nobody but Edward Israel in 1882/83 and the archivist in 2003 laid eyes on. Sergeant Edward Israel was the astronomer who collected the original tidal data. He perished at Cape Sabine on May 29, 1884, 25 years of age.

Edmund Israel, astronomer of the Lady Franklin Bay Expedition of 1881-1884.

Edmund Israel, astronomer of the Lady Franklin Bay Expedition of 1881-1884.

References:

Christie, A.S., 1887: Tidal Observations of the Greely Expedition, Science, 9 (214), 246-249.

Greely, A.W., 1888: Report on the Proceedings of the United States Expedition to Lady Franklin Bay, Grinnell Land, Government Printing Office, Washington, DC.

Guttridge, L., 2000: The ghosts of Cape Sabine, Penguin-Putnam, New York, NY, 354pp.

Formation of Nares Strait Ice Bridges in 2014

Darkness and cold covers North Greenland, Ellesmere Island as well as Nares Strait, the waterway that connects these two inhospitable places. And despite the darkness of the polar night, I can see that three beautiful arches made of ice connect Greenland to Canada. It is possible to walk across water, if the water is frozen. Stuck to land, ice arches or ice bridges shut down ice motion while the ocean under the ice keeps moving. Lets have a peek at how this looked from space yesterday:

Ice arches of Nares Strait on January 26, 2014 from MODIS thermal imagery.

Ice arches of Nares Strait on January 26, 2014 from MODIS thermal imagery. Surface temperatures in degrees Celsius are all below zero despite the missing “-” sign stripped by Adobe Illustrator.

The colors above show the temperature that satellite sensors “see” at the surface of the ice. Red is warm, blue is cold, and grey is land, but “warm” here is still below the freezing point of sea water near -2 degrees Celsius, so even the red or “hot” spots are covered by ice. The 300 deep ocean in Nares Strait generally flows from north to south without trouble under the ice, but just behind the fixed arching ice bridges, it sweeps the newly formed thin ice away to the south. The “warm” spots that form to the south of each ice arches have their own stories:

Farthest to the north a massive ice arch spans almost 200 km (150 miles) across. It faces the open Arctic Ocean to the north and it formed a few days before Christmas 4-5 weeks ago. It was still shedding large ice floes from its edge as it tried, and finally succeeded, I think, to find a stable location. Nevertheless, one of its larger pieces of ice moved into Nares Strait on January-3, 2014 where it became stuck on both Greenland and Ellesmere Islands:

The large floe from the edge of the first ice arch becames firmly lodged on both sides of the 30-km wide entrance to Nares Strait on January-4 (not shown), perhaps aided by strong winds from the north with wind speeds exceeding 40 knots (20 m/s). This second northern arch then aided the formation of the third ice arch in the south. All three arches became first visible on January-8:

Jan.-8, 2014

Jan.-8, 2014

A subsequent lull and short reversal of the winds brought warm southern air masses into Nares Strait while water and drainage pipes froze at my home in Delaware:

Weather record from Hans Island at the center of Nares Strait for January 2014. [Data from Scottish Marine Institute in Oban, Scotland.

Weather record from Hans Island at the center of Nares Strait for January 2014. [Data from Scottish Marine Institute in Oban, Scotland.

“Warm” here refers to -10 degrees Centigrade (+14 Fahrenheit). Air temperatures in Nares Strait today are -21 degrees Celsius (-5 Fahrenheit) while ocean temperatures under sea ice are near -1.8 degrees Celsius (+29 Fahrenheit). It is these “hot” waters that “shine” through the thinner ice as the satellite senses the amount of heat that the ice surface radiates into space. More details on this one finds elsewhere.

I enjoy these elegantly arching ice bridges across Nares Strait, because they challenge me each year anew to question how sea ice, oceans, air, and land all interact to produce them. Nobody really knows. It is a hard problem to model mathematically and many graduate theses will be written on the subject. A student in our own program, Sigourney Stelma, just presented first results and movies of computer simulations of ice bridges forming. Perhaps I can convince her to post some of them on these pages?

Kozo, T.L. (1991). The hybrid polynya at the northern end of Nares Strait Geophys. Res. Let., 18 (11), 2059-2062 DOI: 10.1029/91GL02574

Kwok, R., Pedersen, L.T., Gudmandsen, P. and Peng, S.S. (2010). Large sea ice outflow into the Nares Strait in 2007 Geophys. Res. Let., 37 (L03502) DOI: 10.1029/2009GL041872

Muenchow, A. and H. Melling. (2008). Ocean current observations from Nares Strait to the west of Greenland: Interannual to tidal variability and forcing J. Mar. Res., 66 (6), 801-833 DOI: 10.1357/002224008788064612

Camels in Arctic Canada, Nature Reports

Camels roamed freely the boreal forests of Arctic Canada ages ago. Today, Natalia Rybczynski of the Canadian Museum of Nature in Ottawa published such findings in Nature Communications with Canadian and British scientists. Margaret Munro has the full story.

Illustration of the High Arctic camel on Ellesmere Island during the Pliocene warm period, about three and a half million years ago. [Credit: Julius Csotonyi/Canadian Museum of Nature]

Illustration of the High Arctic camel on Ellesmere Island during the Pliocene warm period, about three and a half million years ago. [Credit: Julius Csotonyi/Canadian Museum of Nature]

My first impression was that of hoax, but here is what the original science article says in the abstract:

Moreover, we report that these deposits have yielded the first evidence of a High Arctic camel, identified using collagen fingerprinting of a fragmentary fossil limb bone. Camels originated in North America and dispersed to Eurasia via the Bering Isthmus, an ephemeral land bridge linking Alaska and Russia. The results suggest that the evolutionary history of modern camels can be traced back to a lineage of giant camels that was well established in a forested Arctic.

Now, the camel is dead for 3.5 million years. It lived at a time when the earth’s climes, oceans, glaciers, and mountains were all different from what they are today with many ice ages that came and went. Bone fragments of this ancient camel were preserved by ice ages long past and today’s cold and dry desert climate of Ellesmere Island.

Good stuff comes out of Canada, and this includes Rick Mercer’s rant about Scientists in Canada 2013.

Rybczynski, N., Gosse, J., Richard Harington, C., Wogelius, R., Hidy, A., & Buckley, M. (2013). Mid-Pliocene warm-period deposits in the High Arctic yield insight into camel evolution Nature Communications, 4 DOI: 10.1038/ncomms2516
